1/4" Dia x 3/4" Solid Carbide Spiral Plunge Router Bit with 1/16" Corner Radius, 1/4" Shank Up-Cut ZrN Coated
Product Details
Features: • 1/4" dia x 3/4" solid carbide spiral plunge with 1/16" corner radius, 1/4" shank up-cut zrn coated router bit • For carving, lettering, decorative doors and sign manufacturing • Leaves an excellent finish and expels chips quickly • Flutes: 2 Excellent for Cutting: • Aluminum • MDF • Soft/Hard Plastic • Soft/Hard Wood Benefits of Zirconium Nitride (ZrN) Coating: • Creates a harder and tougher cutting edge allows for a prolonged cutting edge life and helps to prevent the build-up of material in the flutes while cutting • Have the tendency to run/spin much faster than an uncoated tool • Optimized flute geometry and low Total Indicated Runout (TIR) guarantees clean cuts, essentially eliminates sanding and reduces chatter (where the machine or work piece vibrates) under high chip loads (when used with low TIR spindles) • High flute volume supports high feed rates and chip loads • High aspect ratio for single pass deep-reach cutting • Flute geometry optimized for cutting sign foam, sign board, hardwoods, thermoplastics and phenolic composites
Drilling, sawing, sanding or machining wood products can expose you to wood dust, a substance known to the State of California to cause cancer. Avoid inhaling wood dust or use a dust mask or other safeguards for personal protection. For more information go to www.P65Warnings.ca.gov/wood
Specifications
| Box Quantity | 1 |
| Height | 3/4" |
| Width | |
| Cutting Diameter | 1/4" |
| Application | |
| Material | |
| Product Type | Router Bit |
| Length | 2-1/2" |
| Degree of Cut | |
| Shank Diameter | 1/4" |
