Offset Bowl Layout, Seamless Rim Fit
The Karran Edge 560 is an 18-gauge stainless steel undermount kitchen sink in a large/small bowl configuration, designed for seamless integration into laminate and solid surface countertops. The E-560L places the smaller prep bowl on the right and the larger wash bowl on the left, giving left-dominant workflows their natural primary station. At 32 by 21-1/2 by 9 inches overall, it fits a standard 33-inch or larger sink base cabinet.
Key Features
• Seamless Edge rim bonds flush with laminate and solid surface countertops, eliminating the exposed seam of a conventional drop-in rim.
• Large/small bowl split pairs a full-depth wash basin on the left with a dedicated prep bowl on the right for true two-station workflow.
• 18-gauge Type 304 stainless steel construction provides a durable, food-safe surface with a brushed satin finish that resists everyday surface marks.
• 9-inch bowl depth accommodates tall stock pots and standard colanders without the rim getting in the way.
• Undermount installation keeps the countertop surface continuous, making counter-to-bowl cleanup a single sweep.
• E-560L handed orientation is purpose-built for left-primary layouts, ensuring grids and bowl-specific accessories line up correctly from the start.
Two Stations, One Continuous Counter
An offset bowl layout solves the friction that equal-bowl sinks introduce: you get a primary wash basin that handles full sheet pans and stock pots alongside a smaller station that stays clear for prep, rinsing, or a disposal unit. Because the Edge rim bonds flush with the countertop surface rather than sitting above it, there is no raised edge to trap debris or interrupt the wipe path from counter to bowl. That continuity is especially useful on laminate and solid surface fabrications where a protruding rim would break the surface plane entirely. The 9-inch depth on both bowls means nothing is getting balanced on a shallow ledge during a busy cook session.
Stainless Construction Built for the Work Surface
The E-560L is built from 18-gauge Type 304 stainless steel with a brushed satin finish. The satin texture keeps routine water marks and light contact marks from reading as damage under kitchen lighting. Stainless is non-porous and compatible with standard cleaning products, and the 304 alloy holds up in the wet, detergent-heavy environment of a primary kitchen sink station. The seamless Edge rim is engineered specifically for laminate and solid surface countertops, installed using Karran's documented bevel-bit trimming and seam adhesive method. This is not a conventional undermount that drops beneath the stone; it is a rim-integrated installation where the counter material and the sink edge become one surface.
The Right Sink for Fabricators and Kitchen Renovators
Cabinet shops and countertop fabricators working in laminate or solid surface will find the Edge 560 fits directly into a seamless fabrication workflow without adapting around a conventional rim. For homeowners and designers, the offset bowl configuration suits kitchens where the primary user is right-handed working at the left bowl, or where a disposal is specified for the smaller right bowl only. The E-560L orientation is handed and not reversible, so confirming the layout before ordering is the key step. Grids and bowl-specific accessories are sold separately and are matched to this model by bowl, so ordering them at the same time avoids a separate fit check later.
Frequently Asked Questions
What countertop materials does the Edge 560 install into seamlessly?
Karran documents seamless installation for the Edge Series in laminate and solid surface countertops using the bevel-bit and seam adhesive method. For stone, quartz slab, or granite countertops, a conventional undermount approach is used instead, and a different sink series may be the better fit for those materials.
Which bowl is larger on the E-560L, and which side is it on?
On the E-560L, the large bowl is on the left and the small bowl is on the right. This is a handed model; the orientation is fixed and the sink cannot be flipped to reverse the layout. If a right-large/left-small configuration is needed, look for the E-560R.
Do grids or basket strainers come with this sink?
The E-560L is a bare sink; grids and basket strainers are sold separately. Accessories for this model are matched by bowl, so when ordering, specify which bowl (large or small) each accessory is for to make sure the fit is correct.
What minimum cabinet size does the Edge 560 require?
The sink's 32-inch overall width requires a 33-inch or larger sink base cabinet. Verify the actual sink dimensions against your cabinet and countertop cutout before fabrication, as published dimensions are nominal.
Where does the faucet mount on an undermount Edge sink?
The E-560L has no faucet deck, so the faucet mounts through the countertop behind the sink. Plan faucet hole placement during the countertop fabrication stage, not after the cutout is made.
A Sink That Works as Hard as the Counter Around It
The Edge 560 in its left-large configuration brings a purpose-built offset workflow and a flush seamless rim together in one undermount package, making it a practical choice for fabricators and homeowners who want the sink to disappear into the counter rather than sit above it.
