27" Progressa+ Undermount Drawer Slide for Frameless or Blocked-Out Faceframe Applications, 5/8" Material, 170lb Capacity Full Extension with SMOVE Soft-Closing
Item # SALF70FLSC-27B
•Mfr # G7U6S686CXF2
$48.76
/Pair
4 items
$43.56/Pair
Drawer Length: 27"
Cabinet Type: Frameless (Short)
Material Thickness: 1/2" to 5/8"
Min Order: 1
Qty mult. by: 1
Product Details
Progressa+ SMOVE Heavy Duty Undermount Drawer Slides for Frameless Cabinets or Blocked-Out Faceframe Applications, Up To 5/8" Drawer Thickness
Progressa+ SMOVE is a new generation of heavy duty drawer slides. Rated at 170 Lbs Static load capacity they are suitable for all drawer opening applications.
• 170 Lbs Static load capacity
• Full extension with a synchronized mechanism
• Enhanced smooth soft closing action
• Elongated holes for depth and height adjustment
• Adjustable clips allow for easy drawer insertion and removal
• Special clip for narrow drawers
• Tool free height adjustments + 2.5 mm
• Tool free depth adjustments +/- 3 mm
• Tool free side adjustments +/- 1.5 mm
• Meets and exceeds Ansi BHMA A156.9-2020 Grade 1 standard; WI approved
• Optional tool free tilt adjustment +3 mm
• 13 mm (1/2") to 16 mm (5/8") drawer material thickness
• Compatible with Lineabox drawers
• Finish: bright zinc-plated
• 100% Made in Italy
NOTE: FRONT LOCKING DEVICES REQUIRED AND SOLD SEPERATELY
For Faceframe, block out from the sides of your cabinets. This slide cannot be rear-mounted.
Progressa+ SMOVE is a new generation of heavy duty drawer slides. Rated at 170 Lbs Static load capacity they are suitable for all drawer opening applications.
• 170 Lbs Static load capacity
• Full extension with a synchronized mechanism
• Enhanced smooth soft closing action
• Elongated holes for depth and height adjustment
• Adjustable clips allow for easy drawer insertion and removal
• Special clip for narrow drawers
• Tool free height adjustments + 2.5 mm
• Tool free depth adjustments +/- 3 mm
• Tool free side adjustments +/- 1.5 mm
• Meets and exceeds Ansi BHMA A156.9-2020 Grade 1 standard; WI approved
• Optional tool free tilt adjustment +3 mm
• 13 mm (1/2") to 16 mm (5/8") drawer material thickness
• Compatible with Lineabox drawers
• Finish: bright zinc-plated
• 100% Made in Italy
NOTE: FRONT LOCKING DEVICES REQUIRED AND SOLD SEPERATELY
For Faceframe, block out from the sides of your cabinets. This slide cannot be rear-mounted.
Specifications
| Box Quantity | 2 |
| Length | |
| Finish | Bright Zinc-Plated |
| Drawer Length | 27" |
| Closing Type | Soft-Closing |
| Model | Progressa+ |
| Load Capacity | 170lb |
| Travel | Full Extension |
| Product Type | Undermount Drawer Slide |
| Left or Right | Both (Pair) |
| Cabinet Type | Frameless (Short) |
| Mounting Type | Undermount |
| Material | |
| Slide Type | |
| Height | |
| Certifications | |
| Width | |
| Material Thickness | 1/2" to 5/8" |
| Cabinet Width | |
| Thickness | |
| Overlay |
