Series 100 105° Opening Hinge, 45mm Bore Pattern, Silentia+ Soft-Closing, 1/2", Nickel-Plated, Logica
Item # SALC1J6DE9
•Mfr # C1J6DE9
$3.91
/Each
150 items
$3.34/Each
Mounting Type: Tool-Free
Finish: Nickel-Plated
Min Order: 1
Qty mult. by: 1
Product Details
Silentia+ allows a perfect and constant closing of the door in any condition, use and application. The innovative soft-close technology guarantees excellent performances to the complete range of hinges. Silentia+ includes numerous technological elements in the required spaces and maintains the aesthetics of the hinges of the first generation.
Features:
• Series 100 logica mount 105? opening hinge in Nickel-Plated finish
• Compensated side adjustment from -1.5mm to +4.5mm
• Height adjustment ?2mm
• Depth adjustment with Series 200 mounting plates +2.8mm
• Depth adjustment with Domi snap-on mounting plates from -0.5mm to +2.8mm
• Anti-sliding safety stop
• Symmetrical and asymmetrical bright nickel plated steel or die-cast
• Series 200 mounting plates
• Snap-on assembly on Domi mounting plates
• Positioning with pre-determined stop on traditional Series 200mounting plates
• Use POZIDRIVE No. 2 screwdrivers for all screws
Features:
• Series 100 logica mount 105? opening hinge in Nickel-Plated finish
• Compensated side adjustment from -1.5mm to +4.5mm
• Height adjustment ?2mm
• Depth adjustment with Series 200 mounting plates +2.8mm
• Depth adjustment with Domi snap-on mounting plates from -0.5mm to +2.8mm
• Anti-sliding safety stop
• Symmetrical and asymmetrical bright nickel plated steel or die-cast
• Series 200 mounting plates
• Snap-on assembly on Domi mounting plates
• Positioning with pre-determined stop on traditional Series 200mounting plates
• Use POZIDRIVE No. 2 screwdrivers for all screws
Specifications
| Box Quantity | 1 |
| Product Type | |
| Mounting Type | Tool-Free |
| Overlay | 1/2" |
| Closing Type | Soft-Closing |
| Opening Angle | 105° |
| Model | |
| Hinge Type | Standard Euro Hinge |
| Finish | Nickel-Plated |
| Boring Pattern | 45mm |
| Cup Diameter | 35mm |
| Cup Depth | 12mm |
| Material | Steel |
| Cabinet Type | Face Frame/Frameless |
