Jet Tools HVBS-10-DMWC 10" Horizontal/Vertical Dual Mitering Portable Band Saw with Coolant, 1 Phase/115V
This item may incur additional shipping costs and lead times.
Product Details
The Jet Dual-Mitering Band Saw offers Versatility and ease. The unique head design miters both left and right, allowing for quick angle cuts. Add to the convenience with easy conversion from a horizontal to vertical position, and wheels for moving around the shop floor. Features: • Adjustable vise • Automatic shut off switch stops the sawing process • Blade is fully guarded for Operator Safety • Built-in, self-propelled blade brush prevents chip build up in blade guides • Head is pressure controlled by a hydraulic cylinder • Hydraulic down feed control is easily adjusted enabling feed rates to evolve with variable types of materials • Large 16" x 10" Vertical cutting table • Power switch with Safety key prevents accidental start up • Protractor for fast and accurate angle cutting • Removable chip tray
Specifications
| Box Quantity | 1 |
| Vise Swivels (Deg.) | |
| Rectangle at 45 Degrees | 8" x 5-1/2" |
| Product Type | Mitering Horizontal Bandsaws |
| Prewired Voltage | 115V |
| Overall Height | 46" |
| Overall Dimensions (L x W x H) | 72" x 34.5" x 46" |
| Overall Assembled (Bow Raised) (L x W x H) | |
| Overall Assembled (Bow Lowered) (L x W x H) | |
| Oil Pump Motor | |
| Motor Voltage (V.) | 115V |
| Rectangle at 60 Degrees | |
| Rectangle at 90 Degrees | 8" x 9" |
| Round at 45 Degrees | 6-1/2" |
| Vertical Cutting Capacity | 13" x 10" |
| Throat Depth | |
| Throat Capacity | |
| Table Height | 30-13/32" |
| Square at 90 Degrees | |
| Square at 60 Degrees | |
| Square at 45 Degrees | |
| Round at 90 Degrees | 10" |
| Round at 60 Degrees | |
| Motor Power (HP) | 1 HP |
| Motor Phase | 1 |
| Blade Width | |
| Blade Wheel Diameter | 11 23/32" |
| Blade Speeds (SFPM) | |
| Blade Speed (SFPM) | 64, 132, 247 |
| Blade Size | 1" x 0.035" x 120" |
| Blade Length | |
| Bed Height | |
| Band Saw Size/Wheel Diameter | |
| Amperage Draw @ 115V 1Ph | |
| Configurable Base Item | No |
| Coolant Capacity (Gal.) | |
| Coolant Pump Motor | |
| Motor Amps | |
| Maximum Vise Opening | 10 |
| Head Movement (Deg.) | +/- 45 |
| Enhanced Description | |
| Electrics | |
| Drive | |
| Cutting Capacity Width | |
| Cutting Capacity Height | |
| Cutting Capacity (W x D) | |
| Amperage |
