Tiomos 120° Opening Hinge, 45mm Bore Pattern, Self-Closing, Full Overlay, Nickel-Plated, Dowelled
Item # GTIOF045138489228
•Mfr # F045138489228
Mounting Type: Dowelled
Product Details
Ideal for standard doors, the GRASS Tiomos 110˚ full-overlay hinge is engineered to exceed industry standards for load rating, opening and closing cycles. It allows hassle-free closing of doors, owing to its self-closing function. Its solid metal cup and all moving mechanism parts feature an all-steel construction to last for years. When paired with a compatible baseplate, this self-closing hinge offers convenient three-dimensional adjustment capabilities for door alignment.
Features:
• For face-frame or frameless cabinets
• Allows 3-dimensional adjustment with a suitable base plate
• Accommodates overlays up to 24mm (15/16")
• Optimal reveal up to 24mm door thickness
• Convenient depth adjustment with worm gear
• Steel hinge cup and arm with a nickel-plated finish
Features:
• For face-frame or frameless cabinets
• Allows 3-dimensional adjustment with a suitable base plate
• Accommodates overlays up to 24mm (15/16")
• Optimal reveal up to 24mm door thickness
• Convenient depth adjustment with worm gear
• Steel hinge cup and arm with a nickel-plated finish
Specifications
| Mounting Type | Dowelled |
| Overlay | Full Overlay |
| Closing Type | Self-Closing |
| Opening Angle | 120° |
| Model | |
| Hinge Type | Standard Euro Hinge |
| Finish | Nickel-Plated |
| Boring Pattern | 45mm |
| Cup Diameter | 35mm |
| Cup Depth | 12.6mm |
| Material | Steel |
| Cabinet Type | Face Frame/Frameless |
