18" Progressa Undermount Drawer Slide for Frameless or Blocked-Out Faceframe Applications, 3/4" Material, 120lb Capacity Full Extension with SMOVE Soft-Closing
Item # SALPRGFLSC19-18B
•Mfr # G5U9S457CXF6
$24.04
/Pair
6 items
$23.07/Pair
48 items
$22.77/Pair
96 items
$22.47/Pair
192 items
$22.19/Pair
Drawer Length: 18"
Cabinet Type: Frameless (Short)
Material Thickness: 3/4"
Min Order: 1
Qty mult. by: 1
Product Details
Progressa SMOVE Undermount Drawer Slides for Faceframe or Frameless Applications, Up To 3/4" Drawer Thickness
Progressa SMOVE is a new generation of drawer slides. Rated at 120 Lbs Static load capacity they are suitable for all drawer opening applications.
• 120 Lbs Static load capacity
• Full extension with a synchronized mechanism
• Enhanced smooth soft closing action
• Elongated holes for depth and height adjustment
• Adjustable clips allow for easy drawer insertion and removal
• Special clip for narrow drawers
• Tool free height adjustments + 2.5 mm
• Tool free depth adjustments +/- 3 mm
• Tool free side adjustments +/- 1.5 mm
• Meets and exceeds Ansi BHMA A156.9-2020 Grade 1 standard; WI approved
• Optional tool free tilt adjustment +3 mm
• 19 mm (3/4”) drawer material thickness
• Compatible with Lineabox drawers
• Finish: bright zinc-plated
• 100% Made in Italy
NOTE: FRONT LOCKING DEVICES REQUIRED AND SOLD SEPERATELY
NOTE: REAR MOUNTING BRACKET FOR FACEFRAMES SOLD SEPERATELY
Progressa SMOVE is a new generation of drawer slides. Rated at 120 Lbs Static load capacity they are suitable for all drawer opening applications.
• 120 Lbs Static load capacity
• Full extension with a synchronized mechanism
• Enhanced smooth soft closing action
• Elongated holes for depth and height adjustment
• Adjustable clips allow for easy drawer insertion and removal
• Special clip for narrow drawers
• Tool free height adjustments + 2.5 mm
• Tool free depth adjustments +/- 3 mm
• Tool free side adjustments +/- 1.5 mm
• Meets and exceeds Ansi BHMA A156.9-2020 Grade 1 standard; WI approved
• Optional tool free tilt adjustment +3 mm
• 19 mm (3/4”) drawer material thickness
• Compatible with Lineabox drawers
• Finish: bright zinc-plated
• 100% Made in Italy
NOTE: FRONT LOCKING DEVICES REQUIRED AND SOLD SEPERATELY
NOTE: REAR MOUNTING BRACKET FOR FACEFRAMES SOLD SEPERATELY
Specifications
| Box Quantity | 6 |
| Length | |
| Finish | Bright Zinc-Plated |
| Drawer Length | 18" |
| Closing Type | Soft-Closing |
| Model | PROGRESSA |
| Load Capacity | 120lb |
| Travel | Full Extension |
| Product Type | Undermount Drawer Slide |
| Left or Right | Both (Pair) |
| Cabinet Type | Frameless (Short) |
| Mounting Type | Undermount |
| Material | |
| Slide Type | |
| Height | |
| Certifications | |
| Width | |
| Material Thickness | 3/4" |
| Cabinet Width | |
| Thickness | |
| Overlay |
